FastCharger AC 19.2kW
Most Powerful AC Available

FastCharger AC 19.2kW

This workhorse is the most powerful dual port AC charger on the market. The system was designed to ensure form meets function, with a footprint for limited space applications. This is an ideal solution for commercial charging sites, with an 8-inch HD screen that offers the ability to generate additional ad revenue.

Fast & Efficient
Create an Exceptional Charging Experience

  • At 19.2kW per port, this charger leads the industry by fast charging 2 vehicles simultaneously and generates 75 miles of range within 60 min
  • Design with ISO 15118 Plug & Charge for a hassle-free charging experience

Best-Value Design
Tailored for Commercial Deployment

  • The rugged design can be wall-mounted or floor-mounted
  • One-piece construction makes it easy to install resulting in a lower costs of total owner and a faster ROI

Future-Proof & Flexible to Improve Your Bottom Line

Smart functionality with OCPP 1.6 and 2.0.1 compliant, can adapt its power usage and provide optimal charging today and into the future.
Reduce Capital Investment of power capacity and Operating Expense of demand charges.

Powerful

Powerful

Max 2x19.2kW, Simultaneous Charging of 2 Vehicles

Advanced

Advanced

ISO 15118 Plug & Charge

Convenience

Convenient

Cable Management System

Profitable

Profitable

Generate Advertising Revenue Using 8-Inch High-Definition Screen

Specifications

Product Information

Input/Output Power Rating and Current
2*19.2kW (240V AC*80A)
Output Amperage Adjustable Via Mobile App or DIP Switch, from 6A to 80A On Each Port
Input/Output Voltage
208V±15%; 240V±15%, 60Hz
Network Type
L1/N+PE, L1/L2/PE
Input Cord
Hardwired
Connector Type
SAE J1772, 25’ (7.5m) or 16.4' ('5m)
Ground Fault Detection
20mA CCID
Protection
Over-Current, Over-Voltage, Under-Voltage, Integrated Surge Protection
Card Reader
Optional: ISO 15693, ISO 14443, NFC
Power Measurement Accuracy
+/- 1.0% from 1% to Full Scale

General Characteristics

Enclosure Rating
NEMA 3R
Operating Altitude
6561 Ft.
Operating Temperature Range
-40F ~ +131F
Storage Temperature Range
-40F~+185F
Mounting
Floor Mounted or Wall Mounted
Dimensions (H X W X D)
24.6"x12.6"x6.7" (625mm×320mm×170mm)

User Interface

Status Indication
LED/APP/LCD (8 Inch, 1280x720 Touch Screen)
User Interface
Charge Fast Charge APP; Charge Fast Charge Cloud
Connectivity
Bluetooth, Wi-Fi, Ethernet, 4G, RS485
Communication Protocols
OCPP 1.6J (Can be Upgraded to OCPP 2.0.1 Later)
APP, RFID Card, Credit Cards (Optional)
NEMA 3R

Software Update

Software Update
OTA Updates Via Web Portal

Certification and Standards

Safety and Compliance
UL 2231-1, UL 2231-2, UL2594, NEC Article 625, CSA C22.2, UL 916, ISO 15118 Plug & Charge
EMC compliance
FCC 15 Class B
Certification
Energy Star, Open ADR 2.0b
Warranty
36 Months, Warranty Extension Possible
